PLAN 20-2462
Photographs may show modified designs.
- Jump to:
- All (36)
- Floor plans (2)
Get Personalized Help
Key Specs
1642
sq ft
3
Beds
2.5
Baths
1
Floors
2
Garages
Get Personalized Help
We do our best to get back to you within 24 - 48 business hours.
Need an answer faster? Call now...
Phone: 1-800-528-8070
Phone: 1-800-528-8070
Hours:
Ready for Your Call 7 Days a Week
Every Day 7 am - 8:30 pm Eastern
See our Terms & Conditions and Privacy Policy.
Wow!
Cost to Build Reports
Only $1.99 for Black Friday
Use Code CTBBF (limit 1)
Use Code CTBBF (limit 1)
Our Cost to Build Report gives you a personalized estimate for building your home, based on your location, plan, and materials.
Residential Construction Guide
Learn Building Basics
This downloadable, 26-page guide is full of diagrams and details about plumbing, electrical, and more.
PLAN 20-2462
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-528-8070 for assistance.
Plan Description
Related to plan to 20-2452. Same floorplan, alternate front elevations. You may select the bedroom layout Option #2 below which has walk-in closets and the bathroom accessible from the hallway. The front elevation images show the home built with an optional 3rd car garage.
Floor Plans
Floor Plan - Main Floor
Floor Plan - Other Floor
Full Specs & Features
Dimension
Depth : 47' 8"
Height : 25' 1"
Width : 45'
Area
Garage : 550 sq/ft
Main Floor : 1642 sq/ft
* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Ceiling
Main Ceiling : 9'
Roof
Primary Pitch : 7/12
Roof Framing : Stick - Dimensional Lumber
Exterior Wall Framing
Exterior Wall Finish : Board & Batten / Siding
Framing : 2x6
Bedroom Features
Main Floor Bedrooms
Main Floor Master Bedroom
Split Bedrooms
Walk In Closet
Kitchen Features
Kitchen Island
Walk In Pantry Cabinet Pantry
Additional Room Features
Family Room Keeping Room
Main Floor Laundry
Mud Room
Garage Features
Front Entry Garage
Lot Characteristics
Zero Lot Lines
More
Economical To Build
Jack & Jill Bath
What's Included In This Plan Set
