PLAN 513-2051
Photographs may show modified designs.
- Jump to:
- All (5)
- Floor plans (2)
Get Personalized Help
Key Specs
1881
sq ft
3
Beds
2.5
Baths
2
Floors
3
Garages
Phone: 1-800-528-8070
See our Terms & Conditions and Privacy Policy.
with Code CTB2025 (limit 1)
Residential Construction Guide
Learn Building Basics
This downloadable, 26-page guide is full of diagrams and details about plumbing, electrical, and more.
PLAN 513-2051
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-528-8070 for assistance.
Plan Description
Floor Plans
Floor Plan - Main Floor
Floor Plan - Upper Floor
Full Specs & Features
Dimension
Depth : 56'
Height : 26'
Width : 59'
Area
Bonus: 320 sq/ft
First Floor: 1454 sq/ft
Garage: 703 sq/ft
Second Floor: 437 sq/ft
Roof
Primary Pitch : 10:12
Roof Framing : Roof Trusses
Roof Load : 30/20
Roof Type : Roof Trusses
Secondary Pitch : 8:12
Exterior Wall Framing
Exterior Wall Finish : Brick/Siding
Framing : 2"x4"
Bedroom Features
Main Floor Master Bedroom
Upstairs Bedrooms
Kitchen Features
Breakfast Nook
Kitchen Island
Additional Room Features
Den Office Study Computer
Great Room Living Room
Main Floor Laundry
Sunroom
Unfinished Future Space
Garage Features
Front Entry Garage
Tandem Garage
Lot Characteristics
Suited For View Lot
Outdoor Spaces
Covered Front Porch
Screened Porch
Rooms
Bathroom 2:
18 sq/ft width 6' x depth 3'
Bathroom 3:
40 sq/ft width 8' x depth 5'
Bedroom 1:
184 sq/ft width 15' x depth 12' 4"
Bedroom 2:
132 sq/ft width 11' x depth 12'
Bedroom 3:
132 sq/ft width 11' x depth 12'
Bonus Room - Finished:
318 sq/ft width 24' 6" x depth 13'
Dining Room:
137 sq/ft width 11' x depth 12' 6"
Foyer:
53 sq/ft width 8' x depth 6' 8"
Garage:
418 sq/ft width 19' 4" x depth 21' 8"
Kitchen:
120 sq/ft width 10' x depth 12'
Kitchen Island:
39 sq/ft width 6' 6" x depth 6'
Living Room:
285 sq/ft width 15' x depth 19'
Master Bathroom:
83 sq/ft width 9' x depth 9' 4"
Master Closet:
55 sq/ft width 6' x depth 9' 4"
Nook:
100 sq/ft width 10' x depth 10'
Pantry:
3 sq/ft width 3' x depth 1'
Porch - Screened:
183 sq/ft width 15' 4" x depth 12'
Study:
137 sq/ft width 11' x depth 12' 6"
Utility Room:
46 sq/ft width 7' x depth 6' 8"
What's Included In This Plan Set
- Cover Page: Each home plan features the front elevation and informative reference sections including general notes and design criteria.
- Elevations: Drafted at ¼" scale for the front and 1/8" scale for the rear and sides. All elevations are detailed and an aerial view of the roof is provided, showing all hips, valleys, ridges and framing.
- Foundations: Drafted at ¼" - 1' scale. This plan is designed as a slab foundation. Optional basement or crawl space foundations are available. Basement foundations may require additional engineering for steel beam sizes.
- Main Level Floor Plan: Drafted at ¼" scale. 2" x 4" walls are standard. The detailed drawings include such things as ceiling treatments and header locations.
- Second Level Floor Plan: Drafted at ¼" scale. Drafted to the same degree of detail as the main level floor plan.
- Interior Elevations: Kitchen cabinet elevations are drawn.
- Electrical and Sections: The electrical plan shows suggested electrical layout for the main and second level floor plans. Typical wall, stair, brick sections are provided to further explain construction of these areas.
Plan Set
$1005.00
$1300.00
Foundation
$0.00
$195.00
$195.00
Framing
$0.00
$195.00
Additional Options
$195.00
$165.00
$295.00
$39.00
$165.00
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
