Plan Description

This log design floor plan is 3146 sq ft and has 3 bedrooms and 3.5 bathrooms.

Floor Plans

Floor Plan - Main Floor

Reverse

BUILDER Advantage Program

Pro Builders:

Join the club and save 5% on your first home plan order. PLUS download our exclusive house plans trend report!

Join for FREE

Click to Get Your Trend Report

Floor Plan - Upper Floor

Reverse

Floor Plan - Other Floor

Reverse

Floor Plan - Other Floor

Reverse

Full Specs & Features

Dimension

Depth : 40'

Height : 31' 8"

Width : 40'

Area

First Floor: 1600 sq/ft

Second Floor: 768 sq/ft

Third Floor: 778 sq/ft

* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Roof

Primary Pitch : 6:12

Roof Framing : Conventional

Exterior Wall Framing

Exterior Wall Finish : Log

Framing : Log

Bedroom Features

Fireplace

Main Floor Master Bedroom

Walk In Closet

Kitchen Features

Kitchen Island

Additional Room Features

Great Room Living Room

Loft

Main Floor Laundry

Vaulted / Cathedral Ceilings

Outdoor Spaces

Balcony

Covered Front Porch

Covered Rear Porch

Deck

Rooms

Bedroom 2:

width 13' 5" x depth 14' 4"

Bedroom 3:

width 13' 5" x depth 13'

Great Room:

width 39' x depth 19' 4"

Kitchen:

width 15' 11" x depth 15' 6"

Master Bedroom:

width 13' 5" x depth 19' 4"

Porch Front:

width 38' x depth 8'

What's Included In This Plan Set

See a sample plan set

All plans are drawn at ¼” scale or larger and include :

Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
