PLAN 1083-23
Photographs may show modified designs.
- Jump to:
- All (3)
- Floor plans (1)
Get Personalized Help
Key Specs
4158
sq ft
4
Beds
4.5
Baths
1
Floors
3
Garages
Get Personalized Help
We do our best to get back to you within 24 - 48 business hours.
Need an answer faster? Call now...
Phone: 1-800-528-8070
Phone: 1-800-528-8070
Hours:
Ready for Your Call 7 Days a Week
Every Day 7 am - 8:30 pm Eastern
See our Terms & Conditions and Privacy Policy.
Wow!
Cost to Build Reports
are Only $4.99
with Code CTB2025 (limit 1)
with Code CTB2025 (limit 1)
This report will provide you cost estimates based on location and building materials.
Residential Construction Guide
Learn Building Basics
This downloadable, 26-page guide is full of diagrams and details about plumbing, electrical, and more.
PLAN 1083-23
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-528-8070 for assistance.
Plan Description
This is a gorgeous coastal-style home offering 4,156 square feet of air-conditioned living space. It features two garages—one for two cars and another for one car. The home opens with a grand entrance, leading into an open-concept layout designed for modern living. The spacious kitchen flows into a dining room complete with a wet bar, perfect for entertaining. The private outdoor living area includes a cozy fireplace and an outdoor kitchen, creating an ideal setting for alfresco dining and relaxation. This home is designed for both comfort and luxury, with attention to every detail.
Floor Plans
Floor Plan - Main Floor
Full Specs & Features
Dimension
Depth : 104' 2"
Height : 27' 11"
Width : 82' 1"
Area
Garage : 1059 sq/ft
Main Floor : 6138 sq/ft
Patios : 854 sq/ft
* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Ceiling
Ceiling Details : Coffered ceilings in the Foyer, Great Room, Kitchen, Dining Room, Study, Sitting room, Master Bathroom, Bedrooms 2-4, and the Covered Lanai. Vaulted Ceilings in the Master Suite.
Garage Ceiling : 11' 6"
Main Ceiling : 12'
Roof
Primary Pitch : 6:12
Bedroom Features
Walk In Closet
Kitchen Features
Kitchen Island
Walk In Pantry Cabinet Pantry
Additional Room Features
Den Office Study Computer
Great Room Living Room
Master Sitting Area
Mud Room
Wet Bar
Garage Features
Split Garage
Outdoor Spaces
Covered Rear Porch
Outdoor Kitchen Grill
What's Included In This Plan Set
Please call if building in Lee and Collier Counties of Florida, restrictions apply.
-
Elevations - Drawn at 1/8" to 1/4" Scale, and Includes:
- Material Labels
- Foor-to-Floor Heights
- Roof Slope Indicators
-
Floor Plans - Drawn at 1/8" to 1/4" Scale and Includes:
- Door and Window Sizes
- Completely Dimensioned Floor Plan
- Room Labels and Interior Room Sizes
- Electrical Layouts
- Building Section Markers
- All Electrical Outlets, Fixtures, and Switching
- Floor and Deck Joist Size and Spacing
- Rough-in Plumbing Location (if applicable)
- Mechanical Equipment Locations (if applicable)
- Electrical Locations (if applicable)
-
Roof Design Plan - Drawn at 1/8" to 1/4" scale and Includes:
- All Beam and Header Heights and Locations
- All Hips, Gables, Ridges and Valleys
- Building Section Markers
-
Building Sections - Drawn at 1/8" to 1/4" Scale and Includes:
- Floor Joist Size and Spacing
- Floor-to-Floor Heights
- Non-Typical Plate Heights Indicated
-
Typical Wall Sections - Drawn at 1/8" to 1/2" Scale and Includes
- All Labels Indicating Wall Construction
- Foundation Wall Thickness and Reinforcing
- Insulation Type and Thickness
-
Miscellaneous Notes and Details
- Miscellaneous General Notes
- Stairway details (if applicable)
-
Please Note: This design will not come with a foundation. The foundation should be created by a local structural engineer.
Questions? Call 1-800-528-8070
Plan Set
CAD Set:
$3900.00
$3900.00
For use by design professionals to make substantial changes to your house plan and inexpensive local printing.
PDF Set:
$3900.00
$3900.00
PDF plan sets are best for fast electronic delivery and inexpensive local printing.
Foundation
Stem Wall Foundation:
$0.00
$0.00
Joins the foundation with a house’s vertical walls; often part of stem-wall slab foundation systems, which are constructed like a crawlspace foundation but filled in and compacted, then the slab is poured.
Framing
Block:
$0.00
$0.00
Concrete Block Exterior Walls (Upper Levels may be wood-framed)
Wood 2x4:
$700.00
$700.00
Wood 2x4 Exterior Walls
Wood 2x6:
$700.00
$700.00
Wood 2x6 Exterior Walls
Additional Options
Right-Reading Reverse:
$700.00
$700.00
Choose this option to reverse your plans and to have the text and dimensions readable.
Audio Video Design:
$165.00
$165.00
Receive an overlay sheet with suggested placement of audio and video components.
Comprehensive Material List:
$395.00
$395.00
A complete list of building supplies needed to construct the infrastructure of your new house, plus an overlay of materials shown directly on your PDF (foundation to rooftop with interior and exterior materials), and a detailed, itemized door and window schedule showing all sizes and types. Please allow 5-7 Business Days for completion. Note, the Comprehensive list is only available with a PDF purchase. The Comprehensive list can be ordered no matter what additional plan options you have selected.
Construction Guide:
$39.00
$39.00
Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics.
Lighting Design:
$165.00
$165.00
Receive an overlay sheet with suggested placement of lighting fixtures.
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
Unless you buy an “unlimited” plan set or a multi-use license you may only build one home from a set of plans. Please call to verify if you intend to build more than once. Plan licenses are non-transferable and cannot be resold.
