PLAN 47-1075
Photographs may show modified designs.
- Jump to:
- All (4)
- Floor plans (2)
Get Personalized Help
Key Specs
484
sq ft
1
Beds
1
Baths
2
Floors
2
Garages
Get Personalized Help
We do our best to get back to you within 24 - 48 business hours.
Need an answer faster? Call now...
Phone: 1-800-528-8070
Phone: 1-800-528-8070
Hours:
Ready for Your Call 7 Days a Week
Every Day 7 am - 8:30 pm Eastern
See our Terms & Conditions and Privacy Policy.
Wow!
Cost to Build Reports
Only $1.99 for Black Friday
Use Code CTBBF (limit 1)
Use Code CTBBF (limit 1)
Our Cost to Build Report gives you a personalized estimate for building your home, based on your location, plan, and materials.
Residential Construction Guide
Learn Building Basics
This downloadable, 26-page guide is full of diagrams and details about plumbing, electrical, and more.
PLAN 47-1075
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-528-8070 for assistance.
Plan Description
This handy two-car garage has charm galore, plus additional space on the second level for guests or in-laws, or to be used as a rental apartment. It's a 484 square-foot one-bedroom apartment, with living and dining space, complete kitchen, and full bath. The bedroom contains a box-bay window and wall closet. A deck off the living room is reached via sliding glass doors. The dining room, kitchen, and bath all feature windows. Access this apartment by a stairway to the left of the double garage.
Floor Plans
Floor Plan - Main Floor
Floor Plan - Upper Floor
Full Specs & Features
Dimension
Depth : 22'
Height : 24'
Width : 27' 6"
Area
Garage: 528 sq/ft height 8'
Second Floor: 484 sq/ft
* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Roof
Primary Pitch : 7:12
Roof Framing : Truss
Roof Type : Shingle
Exterior Wall Framing
Exterior Wall Finish : Siding
Framing : 2 x 6
Bedroom Features
Formal Dining Room
Formal Living Room / Parlor
Rooms
Dining Room:
72 sq/ft width 8' x depth 9'
Garage:
483 sq/ft width 21' x depth 23'
Hall Closet:
6 sq/ft width 2' x depth 3'
Kitchen:
77 sq/ft width 9' 4" x depth 8' 4"
Living Room:
90 sq/ft width 9' x depth 10'
Master Bedroom:
108 sq/ft width 9' x depth 12'
Master Closet:
10 sq/ft width 2' x depth 5'
Porch - Front:
44 sq/ft width 4' x depth 11'
Slab Foundation:
528 sq/ft width 22' x depth 24'
