PLAN 23-512

Home > Style > Cottage

Key Specs

910
sq ft

2
Beds

1
Baths

1
Floors

0
Garages

This plan can be customized

Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-528-8070 for assistance.

Modify This Plan

Plan Description

This cottage design floor plan is 910 sq ft and has 2 bedrooms and 1 bathrooms.

Floor Plans

Floor Plan - Main Floor

Reverse

BUILDER Advantage Program

Pro Builders:

Join the club and save 5% on your first home plan order. PLUS download our exclusive house plans trend report!

Join for FREE

Click to Get Your Trend Report

Full Specs & Features

Dimension

Depth : 30'

Height : 18' 3"

Width : 31' 8"

Area

First Floor: 910 sq/ft height 8'

* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Roof

Primary Pitch : 6:12

Roof Framing : Truss

Roof Type : Shingle

Exterior Wall Framing

Exterior Wall Finish : Siding

Framing : 2"x6"

Kitchen Features

Breakfast Nook

Lot Characteristics

Suited For Narrow Lot

Outdoor Spaces

Covered Front Porch

Rooms

Bedroom 1:

132 sq/ft width 12' x depth 11'

Bedroom 2:

90 sq/ft width 10' x depth 9'

Family Room:

208 sq/ft width 15' 8" x depth 13' 4"

Kitchen:

172 sq/ft width 15' 8" x depth 11'

Porch - Front:

118 sq/ft width 29' 8" x depth 4'
