PLAN 45-595
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-528-8070 for assistance.
Plan Description
This authentic raised southern cottage style home requires a very small building site due to the extremely compact layout but the interior is packed with features only found in larger homes. The main level floor plan is open, spacious and airy featuring 9’ ceilings and large windows for maximum view and light. The kitchen is grand and spacious with a buffet serving area and a built-in wine rack. The island has a 42” high raised eating bar and a downdraft cook top. The kitchen and dining areas have exposed beams and easy access to the nearby utility room. The living room has soaring 2 story ceilings with exposed beams and there is wall to wall glass opening to the rear porch. The large wrap around rear porch is designed to take advantage of the slightest breeze and it is sized for rocking chairs. A large front porch is also full depth to provide that down home feel and it is great for spending lazy afternoons, just like at grand mothers home. The stairwell has been designed with railed openings to the living room and dining room eliminating the feel of a dark and un-interesting space. There are built in shelves on each side of the stairwell center wall and great for displaying your favorite photographs or collectables. The master suite is conveniently located on the main level and it has a full bath with a walk-in closet comparable to much larger homes. Upstairs there is a balcony that overlooks the stairwell and the living room below and it has lots of natural lighting provided by the nearby dormer. Two secondary bedrooms and another full bath round out the upper level features of this delightful cottage.
Floor Plans
Floor Plan - Main Floor
Floor Plan - Upper Floor
Full Specs & Features
Dimension
Depth : 44'
Height : 23'
Width : 36'
Area
Main Floor : 902 sq/ft
Porch : 632 sq/ft
Upper Floor : 468 sq/ft
* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Ceiling
Ceiling Details : LIVING ROOM CEILING SLOPES FROM 15' AT THE OUTSIDE WALLS TO 18' IN THE CENTER SECTION. THE CEILING AT THE HIGHEST POINT IS THE SAME HEIGHT AS THE UPPER LEVEL CEILING HEIGHT.
Main Ceiling : 9'
Upper Ceiling Ft : 8'
Roof
Primary Pitch : 10:12
Roof Framing : STICK
Roof Type : GABLE
Exterior Wall Framing
Exterior Wall Finish : VERTICAL SIDING
Framing : 2X6
Insulation : R19
Bedroom Features
Main Floor Master Bedroom
Split Bedrooms
Upstairs Bedrooms
Walk In Closet
Kitchen Features
Breakfast Nook
Eating Bar
Kitchen Island
Additional Room Features
Great Room Living Room
Main Floor Laundry
Mud Room
Lot Characteristics
Suited For Corner Lot
Suited For Narrow Lot
Suited For Sloping Lot
Suited For View Lot
Outdoor Spaces
Covered Front Porch
Covered Rear Porch
Wrap Around Porch
More
Additional Half Bath
Economical To Build
Suited For Vacation Home
Energy Efficient Features
Energy Efficient Design
What's Included In This Plan Set
- Information Cover Sheet
- Foundation Plan: Each plan is designed on a specific type of foundation. Optional foundation types may be offered. Refer to the general information listed with each plan to determine foundation type and options available.
- Detailed Floor Plans: Complete with the window and door schedules. Electrical plans, with suggested switch, fixture and outlet locations, may be part of the floor plan or a separate drawing.
- Exterior Views
- Building Sections & Interior Elevations
- Complete Construction Details
- Complete Specifications: Specifications list the types of materials used in the construction of the home. Finish schedules are provided.
