PLAN 1017-156

Home > Style > Mediterranean Home Plans

Key Specs

3527
sq ft

3
Beds

3.5
Baths

1
Floors

3
Garages

This plan can be customized

Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-528-8070 for assistance.

Modify This Plan

Plan Description

Luxurious single-story living takes a contemporary turn in this well-planned design. Smart details make excellent use of space, like the powder bath that opens out to the lanai. A wet bar tucked into an alcove in the great room gives guests a place to fix their own drinks. In the kitchen, an island provides extra counter space and close proximity to the dining nook, where disappearing walls make this home perfectly summer-ready. The master suite also opens to the back and includes a luxurious bathroom with a view from the tub. This plan is not for sale in Collier and Lee Counties in Florida without the written consent of the designer.

Floor Plans

Floor Plan - Main Floor

BUILDER Advantage Program

Pro Builders:

Join the club and save 5% on your first home plan order. PLUS download our exclusive house plans trend report!

Join for FREE

Click to Get Your Trend Report

Full Specs & Features

Dimension

Depth : 126' 10"

Height : 24' 5"

Width : 54' 8"

Area

First Floor: 3527 sq/ft

Garage: 758 sq/ft

* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Roof

Primary Pitch : 6:12

Roof Framing : Truss

Roof Type : Tile

Secondary Pitch : 8:12

Exterior Wall Framing

Exterior Wall Finish : Stucco

Framing : Block

Bedroom Features

Formal Dining Room

Guest Suite

Main Floor Master Bedroom

Walk In Closet

Kitchen Features

Breakfast Nook

Kitchen Island

Kitchenette Wet Bar

Walk In Pantry Cabinet Pantry

Additional Room Features

Den Office Study Computer

Great Room Living Room

Main Floor Laundry

Open Floor Plan

Vaulted / Cathedral Ceilings

Outdoor Spaces

Courtyard

Covered Front Porch

Covered Rear Porch

Outdoor Kitchen Grill

Rooms

Covered Front Porch:

128 sq/ft

Covered Rear Porch:

516 sq/ft

What's Included In This Plan Set

See a sample plan set

All plans are drawn at ¼” scale or larger and include :

Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.

Questions? Call 1-800-528-8070

Plan Set

CAD Set:
$1200.00

For use by design professionals to make substantial changes to your house plan and inexpensive local printing.

PDF Set:
$1200.00

PDF plan sets are best for fast electronic delivery and inexpensive local printing.

Reproducible Set:
$1200.00

For inexpensive local printing / making minor adjustments by hand. 1 printed set, typically on Bond paper.

Foundation

Slab:
$0.00

Ideal for level lot, single layer concrete poured directly on grade.

Framing

Block:
$0.00

Concrete Block Exterior Walls (Upper Levels may be wood-framed)

Additional Options

Audio Video Design:
$80.00

Receive an overlay sheet with suggested placement of audio and video components.

Construction Guide:
$31.20

Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics.

* Alternate Foundations may take time to prepare.

** Options with a fee may take time to prepare. Please call to confirm.

Unless you buy an “unlimited” plan set or a multi-use license you may only build one home from a set of plans. Please call to verify if you intend to build more than once. Plan licenses are non-transferable and cannot be resold.
