Plan Description

This home overflows with character and detail. Space for entertaining is shared between the dining room and the elegant living room, accented by the zero corner sliding glass doors, and the casual wet bar. The living room is impressive with its fireplace and built-in shelving. On either side of the built-in art niche are two oversized bedrooms with accompanying baths. The kitchen works well with the dinette and its beautiful section of mitered glass. An enormous family room has a warming fireplace and built-in entertainment center. From the family room, living room, or the master suite, double pocket sliding glass doors open to a large lanai, outdoor kitchen and pool area are perfect for entertaining friends and family. Enter the spacious master suite through double doors to find high ceilings, a sitting area, an exercise room and luxurious master bath. The exercise room comes equipped with its own wet bar, and large glass viewing window. The master bath has His and Her walk-in closets, double lavs, sit down vanity, whirlpool tub, and oversize walk-in shower with glass block and mitered glass to view an outdoor garden. Note: First story walls are constructed of concrete block; upper stories are 2 x 6 wood-framed.

Floor Plans

Floor Plan - Main Floor

BUILDER Advantage Program

Pro Builders:

Join the club and save 5% on your first home plan order. PLUS download our exclusive house plans trend report!

Join for FREE

Click to Get Your Trend Report

Floor Plan - Upper Floor

Full Specs & Features

Dimension

Depth : 109' 8"

Height : 34'

Width : 115' 7"

Area

First Floor: 3699 sq/ft

Garage: 952 sq/ft

Second Floor: 704 sq/ft

* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Roof

Primary Pitch : 7:12

Roof Framing : Truss

Roof Type : Tile

Exterior Wall Framing

Exterior Wall Finish : Stucco

Bedroom Features

Formal Living Room / Parlor

Kitchen Features

Breakfast Nook

Butler's Pantry

Kitchen Island

Kitchenette Wet Bar

Additional Room Features

Den Office Study Computer

Exercise Room

Family Room Keeping Room

Main Floor Laundry

Master Sitting Area

Open Floor Plan

Unfinished Future Space

Outdoor Spaces

Deck

Outdoor Kitchen Grill

Rooms

3rd BR Closet:

27 sq/ft width 3' x depth 9'

Bathroom 2:

29 sq/ft width 5' 10" x depth 5'

Bathroom 3:

43 sq/ft width 6' x depth 7' 2"

Bedroom 2:

168 sq/ft width 14' x depth 12'

Bedroom 2 Closet:

27 sq/ft width 3' x depth 9'

Bedroom 3:

160 sq/ft width 13' x depth 12' 4"

Bedroom 3 Closet:

27 sq/ft width 3' x depth 9'

Bedroom 4:

183 sq/ft width 15' 4" x depth 12'

Bedroom 4 Closet:

21 sq/ft width 3' x depth 7'

Bedroom 5:

201 sq/ft width 13' x depth 15' 6"

Bedroom 5 Closet:

36 sq/ft width 4' 2" x depth 8' 8"

Dining Room:

158 sq/ft width 12' 8" x depth 12' 8"

Foyer:

65 sq/ft width 7' x depth 9' 4"

Garage:

1620 sq/ft width 36' 6" x depth 23'

Garage Storage:

43 sq/ft width 6' x depth 7' 3"

Gathering Room:

410 sq/ft width 22' x depth 18' 8"

Kitchen:

244 sq/ft width 16' 8" x depth 14' 8"

Living Room:

256 sq/ft width 16' x depth 16'

Master Bathroom:

169 sq/ft width 14' 6" x depth 11' 8"

Master Bedroom:

168 sq/ft width 14' x depth 12'

Master Closet:

43 sq/ft width 7' 2" x depth 6'

Master Suite:

width 16' x depth 19' 10"

Powder Room:

63 sq/ft width 7' x depth 9'

Study:

154 sq/ft width 12' 6" x depth 12' 4"

Utility Room:

55 sq/ft width 5' 4" x depth 10' 4"

What's Included In This Plan Set

See a sample plan set

All plans are drawn at ¼” scale or larger and include :

Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.

Questions? Call 1-800-528-8070

Plan Set

CAD Set:
$1600.00

For use by design professionals to make substantial changes to your house plan and inexpensive local printing.

PDF Set:
$1600.00

PDF plan sets are best for fast electronic delivery and inexpensive local printing.

Reproducible Set:
$1600.00

For inexpensive local printing / making minor adjustments by hand. 1 printed set, typically on Bond paper.

Foundation

Slab:
$0.00

Ideal for level lot, single layer concrete poured directly on grade.

Additional Options

Additional Construction Sets:
$72.00

Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date).

Audio Video Design:
$80.00

Receive an overlay sheet with suggested placement of audio and video components.

Construction Guide:
$31.20

Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics.

* Alternate Foundations may take time to prepare.

** Options with a fee may take time to prepare. Please call to confirm.

Unless you buy an “unlimited” plan set or a multi-use license you may only build one home from a set of plans. Please call to verify if you intend to build more than once. Plan licenses are non-transferable and cannot be resold.
