PLAN 535-22

Home > Style > Contemporary

Key Specs

8818
sq ft

9
Beds

6
Baths

3
Floors

6
Garages

This plan can be customized

Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-800-528-8070 for assistance.

Modify This Plan

Plan Description

This 3 unit building is a vision of the future in contemporary living. Each unit is 1,700 s.f. with 3 bedrooms and 2.5 baths. To the left of the entry hall, you will find the great room witjh wrap-around, shaded windows and a wet bar passage that leads to the kitchen with counter seating, pantry and outdoor balcony terrace. The diagonal hallway continues to the bedroom area with an abundance of natural light and views to the garden below. The master suite has en-suite bath and walk-in closet, while the 2 other bedrooms have a shared bath. The building allows access to the roof top deck areas is through the stairways or by adding an optional elevator. Indoor parking and storage are located on a lower level under the building. Exterior walls are finished in low maintenance wall tile system and split faced concrete masonry. The building is designed to maximize energy efficiency with ICF exterior walls, energy efficient low-E windows and a thermally designed roofing system. Great Room: 400 sf Kitchen: 180 sf Master Suite: 250 sf

Floor Plans

Floor Plan - Main Floor

BUILDER Advantage Program

Pro Builders:

Join the club and save 5% on your first home plan order. PLUS download our exclusive house plans trend report!

Join for FREE

Click to Get Your Trend Report

Full Specs & Features

Dimension

Depth : 77'

Height : 32'

Width : 35'

Area

Decks : 258 sq/ft

Garage : 1970 sq/ft

Lower Floor : 2140 sq/ft

Main Floor : 2140 sq/ft

Storage : 170 sq/ft

Upper Floor : 2140 sq/ft

* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Ceiling

Garage Ceiling : 8'

Upper Ceiling Ft : 9'

Roof

Roof Framing : Manuf. Wood trusses

Roof Type : Flat

Exterior Wall Framing

Exterior Wall Finish : Ceramic tile, glazed curtain wall, split face CMU on ICF wall panel

Framing : Flooringw/ flat wd. trusses. Walls - 2"x wd. studs or mtl. studs.

Insulation : R-22 to R-30 rated ICF wall panels

Bedroom Features

Walk In Closet

Kitchen Features

Eating Bar

Kitchen Island

Kitchenette Wet Bar

Walk In Pantry Cabinet Pantry

Additional Room Features

Main Floor Laundry

Garage Features

Garage Under

Oversized Garage

Lot Characteristics

Suited For Narrow Lot

Outdoor Spaces

Courtyard

Grill Deck Sundeck

Economical To Build

Jack & Jill Bath

Wheelchair Adaptable

Energy Efficient Features

Energy Efficient Design

What's Included In This Plan Set

See a sample plan set

All plans are drawn at ¼” scale or larger and include :

Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
